C95500 Nickel Aluminum Bronze "9D"

Standards: ASTM B-148, ASTM B-271, ASTM B-505, ASTM B-763, SAE J461, SAE J462, SAE 68B, DIN 2.0975.03

 C95500 aluminum bronze offers superior salt water corrosion resistance. It also is resistant to cavitation and erosion. Along with the advantage of pressure tightness, this high strength alloy is excellent for welding and is available in many forms at a lower cost to you.

COMMON APPLICATIONS

BUILDERS HARDWARE: Window Hardware

CONSUMER: Piano Keys, Musical Instruments

ELECTRICAL: Electrical Hardware

FASTENERS: Stuffing Box Nuts

INDUSTRIAL: Pickling Equipment, Valve Guides, Piston Guides, Valve Seats, Pump Fluid Ends, Glands, Worms, Worms Wheels, Hot Mill Guides, Hand Gun Recoil Mechanisms, Landing Gear Parts, Air Craft Components, Wear Plates, Welding Jaws, Landing Gear Parts, Glass Molds, Machine Parts, Sewage Treatment Applications, Valve Components, Bearings, Bushings, Valve Bodies, Gears

Oil & Gas: Piping for Vertical Pump Columns, Firefighting and Fire Suppression Systems, Seawater Lift Pumps, Piping Layout, Flanges and Fittings, Discharge Elbows, Cooling Loops for Power Plants, Bronze Valve Bodies, Piping Systems, Desalination Equipment, Tube Sheets, Circulating Pumps and Pump Shafts, Fasteners and Hardware for Cooling towers.

MARINE: Marine Applications, Covers for Marine Hardware, Ship Building, Marine Hardware

ORDINANCE: Government Fittings

Specifications

End Product	Specification
Centrifugal	ASTM B271, SAE J462, J461
Continuous	ASTM B505/B505M, SAE J462, J461, QQ-C-390B Type III, MIL-B-16033 Class 4, SAE J461, BS1400 AB2
Ingot	ASTM B30
Precision	ASTM B806
Sand	ASTM B148, B763, SAE J461, J462

c95500 Chemical Composition

	Al	Cu	Fe	Mn	Ni
Min/Max	10.0-11.5	78.0 min	3.0-5.0	3.5	3.0-5.5
Nominals	11.0000	80.0000	4.0000	-	4.3000
