C62400 Aluminum Bronze

ASTM B150

C62300 and C62400 aluminum bronze applications include valve and pump components for industrial process streams, as well as for marine equipment, high strength fasteners and pole line hardware.

Typical Uses for C62400 Aluminum Bronze:

FASTENERS: Nuts, Bolts

INDUSTRIAL: Gears, Bearing Races, Valve Stems, Worm Gears, Valve Guides, Valve Seats, Bearings, Bushings, Cams, Pump Rods

MARINE: Marine Hardware

Chemical Composition
Applicable Specifications
Fabrication
Thermal
Al Cu Fe Mn Si Sn
Min/Max 10.0 - 11.5 Rem 2.0 - 4.5 0.3 0.25 0.2
Nominals 11.0000 86.0000 3.0000 - - -
Product Type Temper Type
Forgings SAE J463, J461
Rod ASTM B150
Rod, Welding AWS A5.7
Temper Sect. Size Cold Work Type Min Temp Tensile Strength YS
0.05% UL 		YS
0.02% Offset 		YS
0.005% Offset 		Elong. RH
B 		RH
C 		RH
F 		RH
30T 		VH
500 		BH
500 		BH
3000 		Shear
Strgth 		Fatigue
Strgth 		Izod
Impact
Strgth
- in. % - F ksi ksi ksi ksi % B C F 30T 500 500 3000 ksi ksi ft-lb
- mm. - - C MPa MPa MPa MPa - - - - - - - - MPa MPa J
BAR
M30 2.99 68 90 40 - - - - - - - - - - - -
M30 76 0 TYP 20 621 276 - - 18 87 - - - - - - - - 0
O50 2.01 68 93 45 - - - - - - - - - - - -
O50 51 0 TYP 20 641 310 - - 14 91 - - - - - - - - 0
O50 1 68 100 50 - - - - - - - - - - - -
O50 25.4 0 TYP 20 689 345 - - 14 92 - - - - - - - - 0
ROD
H02 1 68 105 52 - - - - - - - - - - 65 36
H02 25.4 10 TYP 20 724 359 - - 14 92 - - - - - - 448 248 0
H02 2.99 68 95 47 - - - - - - - - - - 60 34
H02 76 0 TYP 20 655 324 - - 14 91 - - - - - - 414 234 0
M30 4.02 68 90 40 - - - - - - - - - - 58 32
M30 102 0 TYP 20 621 276 - - 18 87 - - - - - - 400 221 0
H02 2.01 68 95 48 - - - - - - - - - - 62 35
H02 51 20 655 331 - - 14 92 - - - - - - 427 241 0
HR50 0.47 95 45 - - - - - - - - - - - -
HR50 12 655 310 - - - - - - - - - - - - 0
95 45 - - - - - - - - - - - -
25-Dec 655 310 - - - - - - - - - - - - 0
0.98 - 1.97 90 43 - - - - - - - - - - - -
25 - 50 620 295 - - - - - - - - - - - - 0
1.97 - 3.15 90 40 - - - - - - - - - - - -
50 - 80 620 275 - - - - - - - - - - - - 0
M20 3.15 - 4.92 90 35 - - - - - - - - - - - -
M20 80 - 125 620 240 - - - - - - - - - - - - 0
Product Property US Customary Metric
Coefficient of Thermal Expansion 9.0 . 10-6 per oF (68-572 F) 16.2 . 10 6? per å¡C (20-300 C)
Density 0.269 lb/in3 at 68 F 7.45 gm/cm3 @ 20 C
Electrical Conductivity 12 %IACS @ 68 F 0.07 MegaSiemens/cm @ 20 C
Electrical Resistivity 86.4 ohms-cmil/ft @ 68 F 14.36 microhm-cm @ 20 C
Melting Point Liquid US 1900 F 1038 C
Melting Point Solid US 1880 F 1027 C
Modulas of Elasticity in Tension 17000 ksi 117000 MPa
Modulas of Rigidity 6400 ksi 44130 MPa
Specific Gravity 7.45 7.45
Specific Heat Capacity 0.09 Btu/lb/å¡F @ 68 F 377.1 J/kg . å¡K at 293 K
Thermal Conductivity 34.0 Btu . ft/(hr . ft2 . å¡F) @ 68 F 58.8 W/m . å¡K at 20 C
Joining Technique Suitability
Brazing Fair
Butt Weld Good
Capacity for Being Cold Worked Poor
Capacity for Being Hot Formed Excellent
Coated Metal Arc Welding Good
Forgeability Rating 80
Gas Sheilded Arc Welding Good
Machinability rating 50
Oxyacetylene Welding Not Recommended
Seam Weld Good
Soldering Not Recommended
Spot Weld Good
End Product Specification
Forgings SAE J463, J461
Rod ASTM B150
Rod, Welding AWS A5.7
